Our new programmable resistor modules are the first to handle up to 2A and 200V, and Microwave Switch Design Tool now has schematic design & simulation capabilities.
We are excited to announce the release of our new family of PXI and PXIe programmable resistor modules—the first that can handle up to 2A and 200V (or as limited by max power) and address both functional test and verification and HIL applications.
Part of our expanding range of medium to high power resistor modules, these PXI (model 40-254) and PXIe (model 42-254) products follow on from the 2.5 W, 5 W, and 10 W, providing a compact, simple solution for applications requiring 1 or 2 resistance channels, with up to 15 W of power handling capability per channel.
Our Microwave Switch Design Tool – a free online tool for configuring application-specific PXI and LXI RF & microwave switching subsystems with just a few clicks -has been updated to include schematic design and simulation capabilities.
The latest iteration of this web-based tool accelerates the design to production process - from block diagram to mechanical layout – and minimizes risk by enabling you to design your own custom RF switching subsystem with an immediate visual indication of electrical performance.
Have questions about the new programmable resistors or Microwave Switch Design Tool? Please feel free to contact us here, and we will be happy to talk to you about your testing needs.
